With over 1000+ Tons and 100+ sizes, we offer from ready stocks Welded and Seamless Boiler Tubes, Air Pre Heater and Corten Steel Tubes along with different varieties of Welded and Seamless Pipes with IBR approval and Cenvat Credit
ERW/CEW Boiler Tubes, Air Heater Tubes and Corten Steel Tubes
manufactured by Tata Steel
Boiler Tubes are made from heat resisting carbon and low alloy steel which can withstand the loads at various pressures and temperatures. Boiler tubes are used for parts of energy type equipments such as boilers, super heaters, economizers, heat exchangers, etc. The tubes are manufactured as hot rolled or cold drawn with welded and seamless manufacturing process. Size and grades of tubes are decided by design of the boilers which are based on the type of fuel, temperatures, pressures and also the quantum of steam required.
Economiser Coils
Super Heater Coils
ERW – Electric Resistant Welded Tubes
Range| Od/THK | 0.9 | 1 | 1.22 | 1.42 | 1.5 | 1.63 | 1.85 | 2.03 | 2.34 | 2.64 | 2.95 | 3.25 | 3.66 | 4.06 | 4.65 | 5.5 | 6 |
| 15.88 | 0.332 | 0.367 | 0.441 | 0.506 | 0.532 | 0.573 | |||||||||||
| 19.05 | 0.403 | 0.445 | 0.536 | 0.617 | 0.649 | 0.700 | 0.785 | 0.852 | 0.964 | ||||||||
| 22.2 | 0.473 | 0.523 | 0.631 | 0.728 | 0.766 | 0.827 | 0.928 | 1.010 | 1.145 | ||||||||
| 23.42 | 0.500 | 0.553 | 0.668 | 0.770 | 0.811 | 0.876 | 0.984 | 1.095 | 1.216 | 1.482 | 1.633 | ||||||
| 25.4 | 0.544 | 0.602 | 0.728 | 0.842 | 0.884 | 0.956 | 1.074 | 1.250 | 1.244 | 1.585 | 1.749 | ||||||
| 28.58 | 0.614 | 0.680 | 0.823 | 0.951 | 1.002 | 1.083 | 1.220 | 1.329 | 1.422 | 1.689 | 1.865 | ||||||
| 31.75 | 0.685 | 0.758 | 0.919 | 1.062 | 1.119 | 1.211 | 1.364 | 1.488 | 1.697 | 1.895 | 2.095 | 2.284 | |||||
| 33.7 | 0.728 | 0.806 | 0.977 | 1.130 | 1.191 | 1.289 | 1.453 | 1.585 | 1.810 | 2.022 | 2.237 | 2.441 | 2.711 | ||||
| 34.93 | 0.756 | 0.837 | 1.015 | 1.174 | 1.237 | 1.339 | 1.510 | 1.648 | 1.882 | 2.104 | 2.328 | 2.541 | 2.824 | ||||
| 38.1 | 0.826 | 0.915 | 1.110 | 1.285 | 1.354 | 1.466 | 1.654 | 1.806 | 2.064 | 2.309 | 2.557 | 2.793 | 3.109 | 3.408 | |||
| 40 | 0.962 | 1.167 | 1.351 | 1.424 | 1.542 | 1.741 | 1.901 | 2.173 | 2.432 | 2.695 | 2.946 | 3.280 | 3.599 | ||||
| 41.28 | 0.993 | 1.205 | 1.396 | 1.472 | 1.594 | 1.799 | 1.965 | 2.247 | 2.516 | 2.789 | 3.048 | 3.396 | 3.727 | ||||
| 44.45 | 1.072 | 1.301 | 1.507 | 1.589 | 1.721 | 1.944 | 2.124 | 2.430 | 2.722 | 3.019 | 3.302 | 3.682 | 4.044 | 4.564 | |||
| 49 | 1.438 | 1.666 | 1.757 | 1.904 | 2.151 | 2.351 | 2.693 | 3.018 | 3.350 | 3.667 | 4.092 | 4.500 | |||||
| 50.8 | 1.228 | 1.492 | 1.729 | 1.824 | 1.977 | 2.233 | 2.442 | 2.797 | 3.136 | 3.481 | 3.811 | 3.255 | 4.680 | 5.292 | 6.144 | ||
| 57.15 | 2.059 | 2.232 | 2.523 | 2.759 | 3.163 | 3.549 | 3.943 | 4.320 | 4.828 | 5.316 | 6.020 | 7.006 | |||||
| 60.3 | 2.358 | 2.667 | 2.917 | 3.345 | 3.754 | 4.172 | 4.573 | 5.112 | 5.631 | ||||||||
| 63.5 | 2.294 | 2.487 | 2.813 | 3.077 | 3.529 | 3.962 | 4.405 | 4.829 | 5.401 | 5.951 | 6.749 | 7.867 | 8.508 | ||||
| 65 | 2.547 | 2.881 | 3.152 | 3.616 | 4.060 | 4.514 | 4.949 | 5.537 | 6.102 | ||||||||
| 69.85 | 2.528 | 2.742 | 3.102 | 3.395 | 3.896 | 3.376 | 4.867 | 5.338 | 5.974 | 6.587 | 7.477 | 8.728 | 9.448 | ||||
| 76.2 | 2.763 | 2.998 | 3.392 | 3.713 | 4.262 | 4.789 | 5.329 | 5.847 | 6.548 | 7.223 | 8.205 | 9.590 | 10.387 | ||||
| 81.2 | 2.948 | 3.199 | 3.620 | 3.963 | 4.551 | 5.115 | 5.693 | 6.248 | 6.999 | 7.724 | 8.778 | 10.268 | 11.127 | ||||
| 82.5 | 2.996 | 3.251 | 3.680 | 4.029 | 4.626 | 5.199 | 5.787 | 6.352 | 7.116 | 7.854 | 8.928 | 10.444 | 11.320 | ||||
| 88.9 | 3.223 | 3.508 | 3.972 | 4.349 | 4.995 | 5.616 | 6.253 | 6.865 | 7.694 | 8.495 | 9.661 | 11.312 | 12.267 | ||||
| 101.3 | 4.019 | 4.551 | 4.985 | 5.728 | 6.443 | 7.177 | 7.883 | 8.840 | 9.766 | 11.118 | 13.035 | 14.146 | |||||
| 114.3 | 4.529 | 5.130 | 5.621 | 6.461 | 7.270 | 8.101 | 8.901 | 9.986 | 11.038 | 12.574 | 14.757 | 16.025 |
-
Not with in the range
-
Non Fin cut
-
Fin cut
Note:
- Values given are in kg/mtr.
- Size range capability may vary based on steel grade.
CEW – Cold Electric Welded Tubes
Range
Note:
- Cold Drawn tubes having internal diameter less than 20mm should be ordered by specifying outside diameter and thickness.
- Normally, CEW tubes are availabe at random lengths of 4 to 6m. However, exact length tubes upto 8m are also available on request.
- Cold Drawn tubes beyond the above mention range maybe taken up on a case-to-case basis.
- Precision Tube manufacturing facility at Tata Steel, Jamshedpur.
General Specifications
| EQ. STANDARD | INDIAN IS |
BRITISH BS |
AMERICAN ASTM |
GERMAN DIN |
JAPANESE JS |
| BOILER TUBES | IS 1914 | BS 3059 PT-1 BS 3059 PT-2 |
ASTM A53 ASTM A178 ASTM A214 |
EN 10217 PT-1 & 2 | JIS G 3461 |
| AIR HEATER TUBES | BS 6323-5 BS 6323-6 |
ASTM A214 ASTM A 423 Gr1 |
DIN 17177 EN 10305-2 & 3 EN 10217-1 & 2 |
JIS G 3461 |
- Superior Weld Quality
- In-house steel making, hot rolling and cold rolling facilities to provide wide range of steel grades.
- Capability to supply high strength tubes with high ductility
- Capability to offer ERW/CEW tubes with tight tolerances on OD and thickness
- Bright normalized surface requirements on request
- In house R&D integrated with resources across the Tata Steel Group
- Fully integrated line with high speed cold draw bench, multi roll straightener, NDT, multi head tube cutting, deburring and packaging system.
- Cold drawn line complete with 10 roll CNC straightener to give a high degree of tube straightness.
- Bright annealing furnace – Fully Automatic roller hearth furnace with provision for Normalizing, Annealing and Tempering.
- Telescopic Front Fork customized tube cutting line to suit customer’s length specification.
- State-of the art surface treatment facility with process parameters like dipping time, rinsing time, drainage angle, holding time controlled through PLC based pre-defined recipe concept.
Certifications received by Tata Steel – ISO 9001, ISO 14001, OHSAS 18001, LLYOYD’S, TS 16949, CENTRAL BOILER BOARD APPROVAL, JIPM STAGE-1 EXCELLENCE AWARD (2004 - first Precision Tube Mill to get JIPM Award).
Click here to view Certificates
